Home : Equipment : Samsung : Camera : 8mm/Hi8 : SCL530

Samsung SC-L530

User Manual

Operating manual
To download the operating manual, right-click the download icon and select "Save As" (or "Save link as", "Save target as", etc).
If you're happy with the manual, a small donation would be very much appreciated. Thanks!

Features

Samsung SC-L530

Specifications

Video format: 8mm / Hi8
Audio:AFM Hi-Fi Mono
Maximum CCD resolution:270,000 pixels
CCD size:0.25 inches
Eyepiece viewfinder:Yes
LCD screen size:2.5 inches
LCD swivel:Yes
Aperture:f/3.6-79.2
Filter diameter:46mm
Optical zoom:22x
Digital zoom:440x
Programmed exposure modes:Auto, sports, portrait, spotlight, high speed shutter, and sand and snow
Autolight:Yes
Hot shoe for external light:No
Image stabilization:Yes
Infrared capability:No
Remote included:Yes
Digital camera capability:No
Included still memory:N/A
Preset titles:Yes
Custom titling:No
Special effects:12 modes including mosaic, mirror, negative, and emboss
Audio sensor:No
Other special features:Photo mode
IEEE1394 output:No
Connections:A/V
S-Video output:No
Battery type:Lithium-ion
Included in box:3-hour Lithium-ion battery, AC adapter / charger, A/V cable, shoulder strap, wireless remote control
Width:7.0 inches
Height:4.13 inches
Depth:4.0 inches
Weight:1.75 lbs
