| Supply Voltage: |
DC 7.2/7.9 V |
| Power Consumption: |
6.8 W (when viewfinder is used), 7.8 W (when LCD monitor is used), 9.2 W (max.) |
| Operating Temperature: |
32 degrees F to +104 degrees F (0 degrees C to +40 degrees C) |
| Operating Humidity: |
10 percent to 85 percent (no condensation) |
| Weight: |
3.652 pounds (1.66 kg), 4.034 lb (1.83 kg) with battery and cassette |
| Dimensions (WxHxD): |
5-1/2 inches x 6-5/16 inches x 14-3/8 inches (139 x 160 x 364 mm) |
| Camera Pick-up Device: |
1/3-inch interline transfer type CCD x 3(progressive modes supported) |
| Camera Picture Elements: |
Total: 410,000 pixels; Effective: 380,000 pixels (horizontal pixel shift system) |
| Camera Lens: |
Leica DICOMAR lens with optical image stabilizer, motorized/manual mode switching, 10x zoom F 1.6 (f = 4.5 to 45 mm) (35 mm equivalent: 32.5 to 325 mm) |
| Camera Filter Diameter: |
72 mm |
| Camera Optical Color Separation: |
Prism system |
| Camera Optical Filter: |
ND Filters, 1/8ND, 1/64ND |
| Camera Gain Selection: |
0, +3, +6, +9, +12, +18 dB (60i mode only) |
| Camera Shooting Mode: |
60i (525i) interlaced fields; Progressive mode (30P, 24P or 24P advance) |
| Camera Preset Shutter Speeds: |
60i mode: 1/60 (OFF), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000 sec.; 30P mode: 1/30, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500,1/1000 sec.; 24P, 24P (ADV) mode: 1/24, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 Sec. |
| Camera Synchro Scan Shutter Speeds: |
60i mode: 1/60.3 to 1/250.0 sec.; 30P mode: 1/30.1 to 1/250.0 sec.; 24P, 24P (ADV) mode: 1/24.1 to 1/250.0 sec. |
| Camera Sensitivity: |
F11.0 at 2000 lux |
| Camera Minimum luminance: |
3 lux (F 1.6, 18 dB gain, 50 IRE video output) |
| VTR Recorded Audio Signals: |
PCM digital recording - 16 bits: 48 kHz/2 channels, 12 bits: 32 kHz/4 channels |
| VTR Recording Tracks: |
Digital video, audio signals: helical track, Time code: helical track (sub-code area) |
| VTR Tape Speed: |
SP mode: 18.812 mm/sec., LP mode: 12.555 mm/sec. |
| VTR Recording Time: |
SP mode: 60 minutes, LP mode: 90 minutes (when AY-DVM63 is used) |
| VTR Tape Used: |
6.35 mm wide metal tape |
| VTR FF/Rew Time: |
Approx. 85 sec. (when AY-DVM60 is used) |
| Video Sampling Frequencies: |
Y: 13.5 MHz, PB/PR: 3.375 MHz |
| Video Quantizing: |
8 bits |
| Video Compression System: |
DCT + variable length code |
| Video Error Correction: |
Reed-Solomon product code |
| Audio Sampling Frequency: |
48 kHz/32 kHz |
| Audio Quantizing: |
16 bits/12 bits |
| Audio Frequency Characteristics: |
20 Hz to 20 kHz |
| Audio Wow and Flutter: |
Below measurable limits |
| Video IN/OUT: |
Pin jack, analog composite input/output, 1.0 Vp-p, 75.(input/output automatically switched) |
| S-Video IN/OUT: |
S-connector, Y/C separate signal input/output, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75.(input/output automatically switched) |
| Audio IN/OUT: |
Pin jacks a2 (CH1, CH2) - Input: 316 mV, high impedance, Output: 316 mV, 600.(input/output automatically switched) |
| DV Connector: |
4-pin, digital input/output, IEEE 1394 standard |
| MIC/Line Input: |
XLR (3 pins) x 2 (CH1, CH2), LINE/MIC switching, high impedance, LINE: 0 dBu, MIC: -50 dBu/-60 dBu (menu selection) |
| DC Input: |
7.9 V |
| Phones: |
Stereo (3.5 mm diameter), 77 mV, 32. |
| CAM Remote: |
Mini jack (2.5 mm diameter) |
| LCD Monitor: |
3.5-inch LCD color monitor, 200,000 pixels |
| Viewfinder: |
0.44-inch LCD color viewfinder, 180,000 pixels |
| Internal Microphone: |
Stereo microphone |
| Internal Speaker: |
20mm round shape, volume - or + |
| Power Source: |
110/120/220/240 V AC, 50/60 Hz |
