Panasonic Lumix DMC-LC1

User Manual

Operating manual
To download the operating manual, right-click the download icon and select "Save As" (or "Save link as", "Save target as", etc).
If you're happy with the manual, a small donation would be very much appreciated. Thanks!




CCD resolution:5.0 megapixels
ISO equivalent:Auto and ISO 100, 200, 400
Maximum shutter speed:8 seconds
Minimum shutter speed:1/2000 second
Resolution modes:2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 1920 x 1080; Motion Image
Optical zoom:3.2x
Digital zoom:3x
Focal length:7 to 22.5 millimeters (equivalent to 28-90mm in 35mm format)
Maximum aperture:F2.4
Aperture modes:F2-F2.4
Memory:SD/MMC card slot
Maximum high-resolution images:N/A
Burst mode:Yes
Continuous shooting speed:Up to 2.7 frames per second
Delay between shots:Information unavailable
Rapid-fire shots:Yes
Display size:2.5 inches
Flash type:Auto, Auto/Red-eye Reduction, Slow Sync/Red-eye Reduction, Slow Sync, Forced On/Red-eye Reduction, Forced On/Off, Flash output Adjustment
Red-eye reduction:Yes
Tripod mount:Yes
Image types:RAW/Super Fine/Fine/Standard
In-camera editing:Information unavailable
Manual features:Full manual zoom, focus, exposure
Special Features:Quicktime Motion JPEG
Batteries:Lithium-ion Rechargeable Battery
Size name:Digital SLR
Length:5.3 inches
Height:3.21 inches
Width:4 inches
Weight:1.38 pounds (body only), 1.55 pounds (with memory card and battery pack)
Software:ArcSoft PhotoImpression, ArcSoft Panorama Maker, ArcSoft PhotoBase, ArcSoft PhotoPrinter, SD Viewer for DSC
System requirements:Each ArcSoft program requires Microsoft Windows 98, Windows 98SE, Windows Me, Windows 2000, Windows XP or Macintosh OS 9 - OS X (Classic mode). SD Viewer requires Microsoft Windows 98SE, Windows Me, Windows 2000 or Windows XP.
What's in the box:Panasonic digital camera, Battery Charger/AC Adapter, Battery Pack, 16MB 6 SD Memory Card, AC & DC Cable, Lens Cap & Lens Hood, Hood Cap, A/V & USB Cable, MC Protector, Remote Shutter, Strap, CD-ROM
