Panasonic DMR-HS2

User Manual

Operating manual
To download the operating manual, right-click the download icon and select "Save As" (or "Save link as", "Save target as", etc).
If you're happy with the manual, a small donation would be very much appreciated. Thanks!


Panasonic DMR-HS2


Disc capacity:1
Progressive scan:Yes
Playback formats:DVD-Video (NTSC), DVD-R, DVD-RAM, red book CD, CD-R, CD-RW, JPEG CD
Recording formats:DVD-R, DVD-RAM
Time Slip:Yes (includes Chasing Playback, Simultaneous Recording and Playback, Time Slip Roller and Button Control
Rapid random access, recording, and playback:Yes
Hard drive storage:40 GB
Recording time:Up to 52 hours (in EP mode)
Relief recording:Yes
Auto renewal recording:Yes
Playlist playback:Yes
Direct Navigator:Yes
One-touch record:Yes
Recording modes:XP/SP/LP/EP/FR
Noise reduction:3D, block, and mosquito
Aspect ratio control:Yes
Video DAC:54 MHz/10-bit
Audio DAC:96 kHz/24-bit
Horizontal resolution:More than 500 lines
Dialog enhancer:Yes
Multi-angle viewing:Yes (with applicable discs)
Frame advance:Yes
Still/freeze frame:Yes
Multilingual support:Yes (English, Spanish, French)
Parental controls:Yes
Recording capability:Yes
Commercial skip:Yes
Bilingual recording:Yes (DVD-RAM only)
Reverse-frame step:Yes
Memory card slot:Yes (compatible with Standard PC Card, SD Memory Card, CompactFlash Card, MultiMedia Card, Smart Media Card, and Memory Stick)
Slow motion:Yes
Audio outputs:2 stereo analog (left/right), 1 optical digital-audio
Audio inputs:3 stereo analog (left/right)
Audio encoding:Dolby Digital 2.0
Headphone jack:No
Video outputs:3 (composite-, component-, and S-video)
Video inputs:3 composite-video, 1 IEEE 1394 digital, 1 RF
Surround-sound output:Dolby Digital and DTS 5.1-channel passthrough
Simulated surround sound:Yes (Advanced Surround V.S.S)
Power source:AC 120V, 60 Hz
Length:12.2 inches
Width:16.9 inches
Height:3.125 inches
Weight:11.2 pounds
