Samsung SC-D180

User Manual

Operating manual
To download the operating manual, right-click the download icon and select "Save As" (or "Save link as", "Save target as", etc).
If you're happy with the manual, a small donation would be very much appreciated. Thanks!

Features

Samsung SC-D180

Specifications

Video signal:NTSC standards
Video recording system:2 rotary heads, Helical scanning system
Audio recording system:Rotary heads, PCM system
Usable cassette:Digital video tape (6.35mm width): Mini DV cassette
Tape speed:SP: approx. 18.81mm/s LP: approx. 12.56mm/s
Tape recording time:SP: 60 minutes (when using DVM 60), LP: 90 minutes (when using DVM 60)
FF/REW time:Approx. 150 sec. (using DVM60 tape)
Image device:CCD (Charge Coupled Device)
Lens:F1.8 12x(Optical), 480x(Digital) Electronic zoom lens
Filter diameter:37
LCD Monitor Pixels:2.5 inches
LCD monitor Method:TFT LCD
Viewfinder:0.24 inch B/W LCD
Video output:1Vp-p
S-video output:Y: 1Vp-p, C: 0. 286Vp-p
Audio output:-7.5dBs
DV input/output:4pin special in/out connector
USB output:Mini-B type connector
External mic:3.5 stereo
Power source:DC 8.4V, Lithium Ion Battery Pack 7.4V
Power source type:Lithium Ion Battery Pack, Power supply (100V~240V) 50/60Hz
Power consumption (Recording):4.9W(LCD), 3.6W(EVF)
Operating temperature:0 - 40 degrees C (32 F - 104 degrees F)
Storage temperature:-20 degrees C - 60 degrees C (-4 degrees F - 140 degrees F)
External dimension:Length 104mm, Height 114mm, Width 53.5mm
Weight:480g (Except for Lithium Ion Battery Pack and tape)
Built-in MIC:Omni-directional stereo condenser microphone
Remote control:Indoors: greater than 15m (straight line), Outdoors: greater than 5m (straight line)
