| Screen size: | 32 inches |
| TV type: | CRT with fine-pitch, dark-tint DynaFlat HD picture tube |
| HDTV capable: | Yes |
| Aspect ratio: | 4:3 |
| Aspect-ratio control: | Normal and zoom (screen-filling) modes |
| Speaker wattage per channel: | 10 |
| Number of speakers: | 2 (2-way each) |
| Comb filter: | 8-bit, 20 MHz, 3D Y/C |
| Electron gun: | Dynamic, multiple-focus |
| Horizontal resolution: | 800 lines (maximum) |
| Invar shadow mask: | Yes |
| Scan velocity modulation: | Yes |
| 3:2 pulldown reversal: | Yes |
| Noise reduction: | Yes |
| Signal type: | NTSC, ATSC (480p/720p/1080i) |
| Protective screen guard: | No |
| Black-level expansion: | Yes |
| White peak limiter: | Yes |
| Auto channel setup: | Yes |
| Auto clock set: | Yes (reads XDS broadcast data) |
| Channel labeling: | Yes |
| Input labeling: | Yes |
| Channel coverage: | VHF 2-13, UHF 14-69, CATV 1-125 (up to 181 pre-selected channels) |
| Closed captioning: | Yes (CaptionVision) |
| Picture modes: | Standard/Dynamic/Movie/Custom (with user-adjustable brightness, contrast, sharpness, color, and tint) |
| Picture enhancements: | Dynamic Multiple Focus Electron Gun, Pro Picture 3-Stage Video Correction; Vertical Compression (maintains vertical resolution and quality during anamorphic widescreen sources such as DVD), Digital Chassis |
| Screen capture picture freezing: | Yes |
| Self-diagnostic mode: | Yes |
| Auto Kine Aging Bias: | Yes (automatically regulates the white balance to maintain consistent, optimal performance even after many years of use) |
| Non-volatile memory: | Yes (preserves settings in the event of a power outage) |
| Electronic program guide: | Yes (Digital Program Guide) |
| Tilt correction: | Yes |
| Last-channel recall: | Yes |
| Multilingual menu: | Yes (English, Spanish, French) |
| Translucent OSD: | Yes |
| Parental control: | Yes (V-Chip) |
| Picture-in-picture (PIP): | No |
| Remote control: | Yes (universal) |
| Discrete IR codes: | Yes |
| SAP: | Yes |
| Sleep timer: | Yes |
| On timer: | Yes |
| Remote Surf timer: | Yes (returns TV to original channel after a fixed time so other channels can be browsed during commercial breaks) |
| Audio tone controls: | Modes for Music, Speech (focuses on dialog and reduces background sounds), and Custom (5-band graphic equalizer allows detailed sound adjustments); plus BBE High Definition Sound Processing |
| Sound enhancement modes: | Standard, Movie, Music, Speech, and Custom |
| Surround sound: | Yes (simulated) |
| VGA/SVGA input: | No |
| Audio outputs: | 1 stereo analog (left/right RCA, fixed-level), 1 optical digital-audio |
| Audio inputs: | 3 stereo analog (left/right) |
| Video outputs: | 1 (composite-video) |
| Video inputs: | 11 |
| Headphone jack: | Yes (.125-inch, side panel) |
| Digital-video input: | 1 (DVI-HDTV) |
| Component video: | 2 (both auto-sensing 480p/480i/720p/1080i) |
| Composite video: | 4 |
| S-video: | 2 |
| RF: | 2 |
| Color temperature control: | Yes |
| Front AV jacks: | No |
| Side AV jacks: | Yes |
| Sound leveler system: | Yes |
| Antenna: | CATV/VHF/UHF 75-ohm, F-type |
| Power supply: | 120W AC, 60 Hz |
| Power consumption: | 190 watts (1.9 watts standby) |
| Energy Star compliant: | Yes |
| UPC: | 036725226852 |
| Width: | 35.9 inches |
| Height: | 27.7 inches |
| Depth: | 22.8 inches |
| Weight: | 147.7 pounds |
| Shipping dimensions: | 40.5 x 33.7 x 27.6 inches (W x H x D) |
| Shipping weight: | 158.7 pounds |
| In the box: | TV, remote control, remote batteries, user's manual |
| Variations: |
TX-P3275HF |
