Sony DCR-SR100


Image device:0.33-inch CCD
Pixel gross:3310K
Recording media:30 GB hard disk drive
Recording and playback time:HQ: 440 minutes; SP: 650 minutes; LP: 1250 minutes
Video actual:2048K pixels
Still actual:3048K pixels
White balance:Auto, indoor, one-push, outdoor
Still image format:JPEG
Minimum illumination:5 lux (0 lux with Super NightShot infrared system)
Input/output:Analog AV input (multi AV), analog AV output (multi AV), digital AV input (via USB), digital AV output (via USB), USB port (2.0 compliant), microphone input (thru active interface shoe), remote jack (mini plug), S-video input (optional accessory), S-video output (optional accessory)
Display:2.7-inch 123K-pixel wide 16:9 touch panel swivelscreen LCD display
Lens type:Carl Zeiss Vario-Sonnar T
Viewfinder:Color (123K pixels)
Microphone:Yes (built-in 5.1 channel)
Focal length (35-millimeter equivalent):42.8 to 495 millimeters (16:9 camera mode), 45 to 450 millimeters (4:3 camera mode), 40.6 to 406 millimeters (16:9 memory mode), 37 to 370 millimeters (4:3 memory mode)
Aperture:f1.8 to f2.9
Exposure:Touch panel (24 steps)
Filter diameter:30 millimeters
Focal distance:5.1 to 51 millimeters
Focus:Full range auto, manual (touch panel)
Shutter speed:Auto, 1/4 to 1/4000 seconds (AE mode)
Zoom:Optical: 10x; digital: 120x
Power supply:InfoLithium battery pack, AC adapter
Power consumption:3.9/4.3 W
Video recording system:MPEG2
Video signal:NTSC color, EIA standards
Analog-to-digital converter:Yes
OS compatibility:Windows 2000 Professional, XP Home/Professional
Dimensions (W x H x D):3.17 x 2.7 x 5.87 inches / 80.5 x 68.5 x 149 millimeters
Weight:1 pound 6 ounces / 615 grams with battery
What's in the Box:DCR-SR100 camcorder, power adapter/in-camera charger (ACL200), InfoLithium rechargeable battery (NPFP60), remote commander remote control (RMT-835), AV cable (stereo), software, USB cable
